Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex
Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Features of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
SMART Current Driver KCD2-SCD-Ex1
1-channel isolated barrier
24 V DC supply (Power Rail)
Current output up to 650 Ω load
HART I/P and valve positioner
Lead breakage monitoring
Housing width 12.5 mm
Up to SIL 2 acc. to IEC 61508
Technical data of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
General specifications of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Signal type Analog output
Functional safety related parameters of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Safety Integrity Level (SIL) SIL 2
Supply of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Connection Power Rail or terminals 9+, 10-
Rated voltage 19 ... 30 V DC
Ripple ≤ 10 %
Rated current ≤ 30 mA at 24 V
Power dissipation ≤ 600 mW at 20 mA and 500 Ω load
Power consumption ≤ 700 mW
Input of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Connection side control side
Connection terminals 5-, 6+
Input signal 4 ... 20 mA , limited to approx. 26 mA
Input voltage open loop voltage of the control system < 30 V
Voltage drop approx. 6 V at 20 mA
Input resistance > 100 kΩ, with field wiring open
Output of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Connection side field side
Connection terminals 1+, 2-
Voltage ≥ 13 V at 20 mA
Current 4 ... 20 mA
Load 0 ... 650 Ω
Ripple 20 mV rms
Transfer characteristics of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Deviation at 20 °C (68 °F), 4 ... 20 mA
< 0.1 % of full scale, incl. non-linearity and hysteresis
Influence of ambient temperature < 2 µA/K (-20 ... 70 °C (-4 ... 158 °F)); < 4 µA/K (-40 ... -20 °C (-40 ... -4 °F))
Frequency range field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 3 kHz (-3 dB)
control side into the field side: bandwidth with 0.5 Vpp signal 0 ... 3 kHz (-3 dB)
Rise time 10 to 90 % ≤ 10 ms
Galvanic isolation of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Input/Output basic insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Input/power supply basic insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Output/power supply reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Indicators/settings of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Display elements LED
Labeling space for labeling at the front
Directive conformity of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Conformity of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Electromagnetic compatibility NE 21:2017
EN 61326-3-2:2018
Degree of protection IEC 60529
Protection against electrical shock UL 61010-1:2012
Ambient conditions of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Ambient temperature -40 ... 70 °C (-40 ... 158 °F)
Mechanical specifications of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Degree of protection IP20
Connection screw terminals
Mass approx. 100 g
Dimensions 12.5 x 114 x 124 mm (0.5 x 4.5 x 4.9 inch) , housing type A2
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
Data for application in connection with hazardous areas of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
EU-type examination certificate CESI 06 ATEX 021
Marking Ex-Hexagon II (1)G [Ex ia Ga] IIC
Ex-Hexagon II (1)D [Ex ia Da] IIIC
Ex-Hexagon I (M1) [Ex ia Ma] I
Output Ex ia
Supply
Maximum safe voltage 250 V AC (Attention! Um is no rated voltage.)
Equipment terminals 1+, 2-
Voltage Uo 25.2 V
Current Io 100 mA
Power Po 630 mW
Internal capacitance Ci 5.7 nF
Internal inductance Li negligible
Certificate CESI 19 ATEX 021 X
Marking Ex-Hexagon II 3G Ex ec IIC T4 Gc
Galvanic isolation of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Input/Output safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Output/power supply safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-7:2015
International approvals of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
FM approval
FM certificate FM 18 CA 0116 X , FM 19 US 0117 X
Control drawing 116-0469 (cFMus)
UL approval E106378
Control drawing 116-0459 (cULus)
IECEx approval
IECEx certificate IECEx CES 06.0001X
IECEx marking [Ex ia Ga] IIC , [Ex ia Da] IIIC , [Ex ia Ma] I
Ex ec IIC T4 Gc
General information of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.
Classifications of Pepperl+Fuchs KCD2-SCD-Ex1 SMART Current Drivers KCD2-SCD-Ex1 Safety Barriers Arrived
System Classcode
ECLASS 11.0 27210120
ECLASS 10.0.1 27210120
ECLASS 9.0 27210120
ECLASS 8.0 27210120
ECLASS 5.1 27210120
ETIM 8.0 EC002653
ETIM 7.0 EC002653
ETIM 6.0 EC002653
ETIM 5.0 EC001485
UNSPSC 12.1 32101514
